| Name of the Lab | CAD Laboratory |
|---|---|
| Year of Establishment | 2013 |
| Venue | Cambridge Block |
| Room No. | 2208 |
| Area | 83.64 Sq.m |
| Faculty In-charge | Dr.R.Meby Selvaraj, Assistant Professor (SG) / Mechanical |
| Lab Technician | Mr.A.Kamal, D.M.E. |
Lab courses Handled in the Lab:
Course Code | Course Name | Year & Semester |
ME 3381 | Computer Aided Machine Drawing | II & III |
The following are the main objectives of CAD Laboratory:
- To present an overview of CADD and describe its application in different fields
- To improve the visualization ability of machine components and assemblies before their actual production through modeling, animation, rendering and coloring.
- To acquire hand on experience in design and preparation of detail drawings for machine components normally encountered in Mechanical Engineering practice
EQUIPMENT DETAILS
S.No. | List of Equipment |
1. | Intel Core I9 – computer, with suitable graphics facility. |
2. | A3 size plotter |
3. | Laser Printer |
4. | Any High-end integrated modeling and manufacturing CAD software (CREO 3.0) |
5. | Multibody Dynamic Software Suitable for Mechanism simulation and analysis (Ansys 17.0) |
